ATC450-C Wireless Temperature Monitor

ATC450-C


● Power supply: DC24V
● Points: ≤60
● Communication: RS485(MODBUS-RTU)


Description

General

ATC450-C wireless temperature transceiver can adopt guide rail (DIN35mm) installation or bolt fixing.



Technical Parameter


ItemFeatures

Transceiver

ATC450-C
Power SourceDC24V
Power Consumption
≤1W
points
≤60
Resolution
0.1℃
Communication
RS485
Protocol
MODBUS-RTU
Baud rate (bps)
2400、4800、9600、19200
Environment
Temperature:-20 ℃～+55 ℃；Humidity:≤95%

Dimension





Typical Connection



Package



MINIMUM PACKAGE







MINIMUM PAKAGE


Package dimensions(1 PC)

170*150*130mm

Pakage Weight(1 PC)

0.2Kg


WHOLE BOX PAKAGE


Package dimensions(36 PCS)

450*240*250mm

Pakage Weight(36 PCS)

7.2kG


PRODUCT HS CODE


 9025191010

ATTENTION !

The above packing and weight data are only refer to model ATC450-C.

For other models or optional functions, please contact the salesman for details, thank you for your cooperation!
